[vc_row][vc_column width=”2/3″][vc_column_text]CARACTERÍSTICAS:
• Alcance de 4kW – 45k, Anti-faixa, resina do estator auto-curativa previne que o motor sobreaqueça
• Estator hermeticamente fechado
• Water lubricated radial and thrust bearing
• Corrosion resistant AISI 304 SS material
• Removable Water Bloc™ lead connector
• Anti-track, self healing stator resin prevents motor burn out
• Non-contaminating water filling
• High efficiency electrical design (lower operating cost, lower winding temperature)
• Automatic reversal starting torque
• KTW/VDE approved motor leads
ESPECIFICAÇÕES:
• 6” NEMA falange
• Grau de protecção: IP 68
• Isolamento: Cl. B
• Temperatura ambiente: 30°C
• Inicios/h: 20
• Montagem: vertical/horizontal
• Tolerância da voltagem: +6% / -10% UN (Normal: 415 + 6% = 440V, 380 – 10% = 342V
• Protecção do motor: Integrado
• Cabo do motor: 3x 1,5 mm² ; 1,5 m[/vc_column_text][vc_empty_space height=”50px”][vc_message style=”square” icon_fontawesome=”fa fa-file-pdf-o”]Clique aqui para visualizar o PDF informativo.[/vc_message][/vc_column][vc_column width=”1/3″][vc_single_image image=”3936″ css=”.vc_custom_1706798113744{background-color: #ecece7 !important;}”][/vc_column][/vc_row][vc_row][vc_column width=”1/3″][/vc_column][vc_column width=”1/3″][vc_empty_space height=”69px”][/vc_column][vc_column width=”1/3″][/vc_column][/vc_row][vc_row column_spacing=”20″ css=”.vc_custom_1654704206182{background-color: #ecece7 !important;}”][vc_column width=”1/3″][vc_empty_space height=”50px”][vc_column_text]joval.pt[/vc_column_text][vc_empty_space height=”36px”][vc_column_text]Página inicial
