Pressure Tanks

Stainless steel tanks for storage and stabilization of hydraulic systems.

Pressure Tanks

Pressure Tanks · Specification range

JOVAL supplies AISI 304 pressure tanks with a replaceable EPDM membrane (VIM series) or without a membrane (VI series), from 20 to 600 L, for booster sets and pressurisation networks.

Material
AISI 304 stainless steel (1.4301)
Capacities (with membrane)
20 – 200 L
Capacities (membrane-free)
60 – 600 L
Max pressure
5 / 6 / 8 bar (pre-charge 2 bar)
Membrane
Replaceable EPDM (or membrane-free)
Standards
European PED Directive

Frequently asked questions

  1. What is the difference between a membrane tank and a membrane-free tank?

    A membrane tank uses an EPDM bladder that separates water from the compressed air. A membrane-free tank is a cylindrical vessel with direct contact, for duties where that contact is acceptable.

  2. How do I size the pressure-tank volume?

    It depends on pump flow, pressure differential and starts per hour (typically 15 to 20). For booster sets: 100 L for 2–3 m³/h, 200 L for 5 m³/h, 300 L for 10 m³/h.
